DG Series Starch Air Stream Dryer

DG Series Starch Air Stream Dryer
DG Series Starch Air Stream Dryer

DG Series Starch Air Stream Dryer

Pneumatic drying configured for starch processing.

Suitable for: starch materials within the operating range.
Model:DG
WhatsApp Now
WHAT ARE YOU LOOKING FOR?
*
This field is required
Total quantity you need
*
This field is required
*
This field is required
Email format error
Due to email instability, you might miss our correspondence. Please provide your phone number for alternative contact.
This field is required
Telephone information is wrong!
Send Message
  • Overview & Principle
  • Features & Materials
  • Applications
  • Technical Parameters
  • FAQ
Product Overview
The DG Series Starch Air Stream Dryer provides pneumatic drying configured for starch processing. Typical materials and duties include starch materials within the operating range.
Working Principle

Wet starch is dispersed into a high-velocity hot-air stream and conveyed through the drying line. Moisture evaporates during the short pneumatic residence time, after which the dried starch is separated from the exhaust air.


Key Features
Designed for pneumatic drying configured for starch processing.
The equipment and control configuration are selected according to the material and process requirements.
Suitable Materials
Starch materials within the operating range.
Material suitability should be confirmed through review of physical properties, moisture or solvent content, temperature sensitivity and the required final product condition.


Wide Range of Applications
Applications include starch materials within the operating range. Final suitability should be confirmed from the material characteristics and process requirements.


Technical Parameters

ModelDG0.5DG0.8DG1DG1.2DG1.6DG2DG2.6DG3.2DG3.6DG5DG6DG10DG20
Starch Output (t/h)0.50.811.21.622.63.23.6561020
Total Power (kW)16.321.624.626.630.147.659.57595123.4170223.5440
Steam Consumption (kg/kg water)1.8–2.01.8–2.01.8–2.01.8–2.01.8–2.01.8–2.01.8–2.01.8–2.01.8–2.01.8–2.01.8–2.01.8–2.01.8–2.0
Initial Moisture Content of Product (%)12–1412–1412–1412–1412–1412–1412–1412–1412–1412–1412–1412–1412–14


Frequently Asked Questions
What is the primary function of the DG Series Starch Air Stream Dryer?
Its primary function is pneumatic drying configured for starch processing.
What materials can be processed?
Starch materials within the operating range. Final suitability should be confirmed through material and process evaluation.
How should a model be selected?
Confirm feed moisture and physical form, dispersion behaviour, allowable product temperature, required evaporation duty, gas velocity and separation arrangement.
