WLDH Series Horizontal Ribbon Mixer

WLDH Series Horizontal Ribbon Mixer
WLDH Series Horizontal Ribbon Mixer

WLDH Series Horizontal Ribbon Mixer

Counter-directed ribbon movement in a horizontal mixing trough.

Suitable for: dry powders, granules and compatible mixtures suited to ribbon blending.
Model:WLDH
WhatsApp Now
WHAT ARE YOU LOOKING FOR?
*
This field is required
Total quantity you need
*
This field is required
*
This field is required
Email format error
Due to email instability, you might miss our correspondence. Please provide your phone number for alternative contact.
This field is required
Telephone information is wrong!
Send Message
  • Overview & Principle
  • Features & Materials
  • Applications
  • Technical Parameters
  • FAQ
Product Overview
The WLDH Series Horizontal Ribbon Mixer provides counter-directed ribbon movement in a horizontal mixing trough. Typical materials and duties include dry powders, granules and compatible mixtures suited to ribbon blending.
Working Principle

Inner and outer helical ribbons rotate within the horizontal trough and move material in opposite axial directions. The resulting convection, circulation and shear repeatedly redistribute the batch.


Key Features
Designed for counter-directed ribbon movement in a horizontal mixing trough.
The equipment and control configuration are selected according to the material and process requirements.
Suitable Materials
Dry powders, granules and compatible mixtures suited to ribbon blending.
Material suitability should be confirmed through review of physical properties, moisture or solvent content, temperature sensitivity and the required final product condition.


Wide Range of Applications
Applications include dry powders, granules and compatible mixtures suited to ribbon blending. Final suitability should be confirmed from the material characteristics and process requirements.


Technical Parameters

ModelWLDH-0.1WLDH-0.3WLDH-0.5WLDH-1WLDH-1.5WLDH-2WLDH-3WLDH-4WLDH-6WLDH-8WLDH-10
Batch Capacity (kg)30–50100–150200–300400–600600–900800–12001200–18001600–24002400–36003200–48004000–6000
Motor Power (kW)1.5–43–5.54–117.5–1511–18.515–2218.5–3022–3737–5537–5545–75
Equipment Weight (kg)30050090014001900250031003600530068007800


Frequently Asked Questions
What is the primary function of the WLDH Series Horizontal Ribbon Mixer?
Its primary function is counter-directed ribbon movement in a horizontal mixing trough.
What materials can be processed?
Dry powders, granules and compatible mixtures suited to ribbon blending. Final suitability should be confirmed through material and process evaluation.
How should a model be selected?
Confirm batch size, bulk density, flow behaviour, required uniformity, permissible shear, loading and discharge method, cleaning needs and available space.
