QZL Series Ball Granulating Machine (Pelleting machine )（Ball Shape Granulator)



Principle
this machine makes damp granule into beautiful pellet by setting rotating centrifugal disk, blower, and pneumatic nozzle. Feed damp granule into rotating centrifugal disk, start fan then start rotating centrifugal disk. It can make the damp granule in float and circle by the air from gap, rotating centrifugal strength and itself gravity, appear circle rope-turning movement and become high-degree ball shape pellet.



Features
1.Produce pellet size between 0.5~2.0mm
2. Process long granule becomes pellet.
3. Simple operation & effective operation time.



Application

With the special design of rotor structure, the machine makes various wet grains into the perfect ball shape pellets. It is the desired equipment for making the capsules and pills of traditional Chinese medicine.
1. Pharmaceutical, Food Industries 2. Cosmetic, Dyestuff, Coloring Industries 3. Ceramic Industry

Technical parameters

spec	Ø230	Ø400	Ø700	Ø1000
power(Kw)	0.75	2.2	3.7	5.5
capacity(kg/h)	10-100	20-150	30-200	40-300

•
